1.Application：

This machine is suitable for the processing and production of all kinds of textile fabrics, such as knitting, weaving, warp knitting, and so on. It has the function of correcting cloth guide, widely used in the production process of fabric grinding, setting and printing, and also in the fields of pre treatment, mercerization and so on.

2.Technical characteristics:

①. Power: 380VAc50Hz

②.Power consumption: 2.5KW

③.Mechanical width: 800mm-4000mm

④.Adapt to the humidity of the environment: -10 C - +50 C

2. 3. Effect of energy-saving

①. the machine has two functions of correcting and expanding, which is made up of expansion box, rectifying device and infrared phototube.

②.the widening box is mainly composed of stainless steel widening roller and motor. The stainless steel roller surface is evenly twisted with stainless steel "round wire" or "flat silk" and fixed. After polishing, the surface is smooth and the surface of the fabric is not damaged and hair is not shund when the fabric is enlarged.

③.the rectifying device is controlled by the sliding rod roller through the frequency conversion drive to synchronize the fabric with the equipment line speed. The slider roller can be divided into the suede and the light surface controlled by the cylinder; the fabric can be effectively corrected by the contact surface of different fabric, and the slider between the sliders makes the fabric soothing after the gap makes the hard pull damage.
